Connecting to Azure IoT Hub
Step-by-step guide to connect your M2M Gateway to Microsoft Azure IoT Hub for cloud-based monitoring and management.
Connecting M2M Gateway to Azure IoT Hub
Seamless integration with Microsoft Azure IoT Hub for enterprise-grade cloud connectivity
Video Tutorial: Complete Azure Setup
Prerequisites
- CONPROSYS M2M Gateway device
- Azure account with active subscription
- IoT Hub resource created in Azure Portal
Azure Portal showing IoT Hub configuration dashboard
Step 1: Create IoT Hub
- Login to Azure Portal
- Click "Create a resource"
- Search for "IoT Hub"
- Configure:
- Subscription: Your subscription
- Resource Group: Create new or use existing
- Region: Select nearest region
- IoT Hub Name: Unique name
- Tier: S1 (recommended for production)
Pricing Tiers Comparison
| Tier | Messages/Day | Cost/Month | Use Case |
|---|---|---|---|
| F1 | 8,000 | Free | Development & testing |
| S1 | 400,000 | $25 | Production - small scale |
| S2 | 6,000,000 | $250 | Production - medium scale |
| S3 | 300,000,000 | $2,500 | Production - large scale |
Step 2: Register Device
Using Azure Portal
- Go to your IoT Hub
- Click "Devices" under "Device management"
- Click "Add Device"
- Enter Device ID (e.g., gateway-001)
- Leave authentication as "Symmetric key"
- Click "Save"
Using Azure CLI
Open PowerShell and run:
bash# Install Azure CLI (if not installed)
winget install Microsoft.AzureCLI
# Login to Azure
az login
# Create IoT Hub device
az iot hub device-identity create \
--hub-name your-iot-hub \
--device-id gateway-001
# Get connection string
az iot hub device-identity connection-string show \
--hub-name your-iot-hub \
--device-id gateway-001 \
--output table
Step 3: Configure M2M Gateway
Web-based configuration interface for cloud connectivity
Access Web Interface
- Open browser to gateway IP address (default: 192.168.1.1)
- Login with admin credentials
- Navigate to "Cloud" > "Azure IoT Hub"
Connection Configuration Code
python# Python example for programmatic configuration
import requests
import json
GATEWAY_IP = "192.168.1.1"
ADMIN_USER = "admin"
ADMIN_PASS = "your-password"
# Azure IoT Hub connection string
CONNECTION_STRING = "HostName=your-hub.azure-devices.net;DeviceId=gateway-001;SharedAccessKey=your-key"
def configure_azure_connection():
config = {
"enabled": True,
"connectionString": CONNECTION_STRING,
"transmissionInterval": 60, # seconds
"batchSize": 100,
"retryEnabled": True,
"bufferSize": 1000,
"tlsEnabled": True
}
response = requests.post(
f"http://{GATEWAY_IP}/api/cloud/azure",
json=config,
auth=(ADMIN_USER, ADMIN_PASS)
)
if response.status_code == 200:
print(" Azure IoT Hub configured successfully")
print(json.dumps(response.json(), indent=2))
else:
print(f" Configuration failed: {response.text}")
configure_azure_connection()
Configure Data Transmission
- Interval: 60 seconds (adjustable 1-3600s)
- Batch Size: 100 messages (max 500)
- Retry Logic: Enabled with exponential backoff
- Buffer Size: 1000 messages (disk-backed)
- Compression: Optional gzip compression
Step 4: Verify Connection
Real-time connection monitoring and telemetry dashboard
Check Gateway Status
- Status indicator should show "Connected" (green)
- View message count in dashboard
- Check last transmission timestamp
- Monitor queue depth
Check Azure Portal
- Go to IoT Hub resource
- Click on your device ID
- View "Messages" tab
- Should see incoming telemetry with timestamps
Monitoring Script
javascript// Node.js script to monitor Azure IoT Hub messages
const { EventHubConsumerClient } = require("@azure/event-hubs");
const connectionString = "YOUR_EVENT_HUB_COMPATIBLE_CONNECTION_STRING";
const consumerGroup = "$Default";
async function monitorMessages() {
const client = new EventHubConsumerClient(consumerGroup, connectionString);
console.log(" Monitoring Azure IoT Hub messages...");
const subscription = client.subscribe({
processEvents: async (events, context) => {
for (const event of events) {
console.log(" Message received:");
console.log(" Device:", event.systemProperties["iothub-connection-device-id"]);
console.log(" Time:", event.systemProperties["iothub-enqueuedtime"]);
console.log(" Body:", event.body);
console.log("---");
}
},
processError: async (err, context) => {
console.error(" Error:", err);
}
});
// Run for 60 seconds
await new Promise(resolve => setTimeout(resolve, 60000));
await subscription.close();
await client.close();
}
monitorMessages();
Step 5: View Data
Using Azure IoT Explorer
- Download Azure IoT Explorer
- Add your IoT Hub connection string
- Select your device from the list
- View telemetry in real-time with charts
Using Azure Portal
- Go to IoT Hub
- Click "Monitor" > "Metrics"
- Add metric: "Telemetry messages sent"
- View in line charts with time range selector
Message Format
Default JSON format sent to Azure:
json{
"deviceId": "gateway-001",
"timestamp": "2025-11-18T10:30:00Z",
"location": "Factory-A",
"values": {
"temperature": 25.5,
"humidity": 60.0,
"pressure": 1013.25,
"vibration": 0.05,
"status": "running"
},
"metadata": {
"firmware": "2.4.1",
"signalStrength": -65
}
}
Advanced Configuration
Custom Message Properties
javascript// Add custom properties for Azure IoT Hub routing
const message = {
body: telemetryData,
properties: {
location: "Factory-A",
equipment: "Compressor-01",
alarm: "false",
priority: "normal"
}
};
Device Twin Configuration
json{
"desired": {
"telemetryInterval": 60,
"alertThresholds": {
"temperature": 80,
"pressure": 10
},
"enabled": true
},
"reported": {
"telemetryInterval": 60,
"firmwareVersion": "2.4.1",
"lastReboot": "2025-11-18T08:00:00Z"
}
}
Download Resources
- Azure IoT Hub Setup Guide - Complete walkthrough (4.2MB)
- Security Best Practices - Production deployment guide (2.8MB)
- Sample Code Repository - Python, Node.js, C# examples (3.5MB)
- Troubleshooting Checklist - Common issues resolved (1.2MB)
Troubleshooting
Connection Failed
- Verify connection string is correct (no spaces)
- Check firewall allows port 8883 (MQTT over TLS)
- Ensure gateway has internet access
- Verify DNS resolution works
- Check system time is synchronized (NTP)
Messages Not Arriving
- Check gateway buffer usage in web UI
- Verify Azure IoT Hub quotas not exceeded
- Review message size limits (256KB max per message)
- Confirm device is not throttled
- Check Azure service health status
Authentication Errors
- Regenerate device keys in Azure Portal
- Update connection string in gateway
- Verify device is enabled in IoT Hub
- Check clock sync on gateway (±15 min tolerance)
- Ensure SAS token not expired
Security Best Practices
End-to-end security with TLS encryption and certificate authentication
- Use TLS/SSL: Always enabled by default (port 8883)
- Rotate Keys: Change device keys every 90 days
- Monitor Access: Review device activity logs daily
- Use DPS: Device Provisioning Service for zero-touch provisioning
- Certificate Auth: Use X.509 certificates for production
- Network Isolation: Use VPN or private endpoints
- RBAC: Implement Role-Based Access Control
